| Model |
4LH-DTE |
| Configuration |
4 Stroke, Vertical, Water
Cooled Diesel Engine |
| Number of Cylinders |
4 In-line |
| Bore x Stroke |
3.94" x 4.33" (100mm
x 110mm) |
| Displacement |
210.86" (3.455 L) |
| Continuous Rating Output at Flywheel |
154 HP/3200 rpm
(113.3 kW/3200 rpm) |
| Maximum Output at Flywheel |
170 HP/3300 rpm
(125kW/3300 rpm) |
| Combustion System |
Direct Injection |
| Aspiration |
Turbocharged with Intercooler |
| Starting System |
Electric Starting
(DC 12V, 2.5kW Starting Motor/12V 55A AC Generator) |
| Cooling System |
Fresh Water Cooling by
Centrifugal Fresh-Water Pump and
Rubber Impeller Seawater Pump |
| Lubrication System |
Forced Lubrication with Gear
Pump |
| Rotation |
Counter Clockwise (Viewed from
Stern) |
| Dry Weight |
895.1 lbs. (406 kg) |
